Nuestras transpaletas eléctricas de conductor sentado NPS20-30N2 ofrecen potencia, velocidad y todo el equipamiento necesario para operaciones intensivas de transporte interno. Son perfectas para trasladar con rapidez cargas largas y pesadas a grandes distancias, y se caracterizan por su tamaño compacto y su alta maniobrabilidad en espacios reducidos. Resultan muy prácticas, por ejemplo, en plantas de producción, centros de logística, almacenes, muelles de carga o empresas donde se trabaja por turnos.

¿Por qué elegir una transpaleta eléctrica de conductor sentado NPS20-30N2?

Los altos niveles de ergonomía y confort de estas transpaletas Cat® ayudan al conductor a rendir al máximo. El diseño ergonómico del habitáculo minimiza la emisión de ruidos y vibraciones, y reduce notablemente el estrés, la tensión y la fatiga por muy largo y pesado que sea el turno. Es espacioso, permite entrar y salir con facilidad, y lleva un asiento con suspensión regulable. Y, para disfrutar de más comodidad y rendimiento, es posible añadir extras como, por ejemplo, el suelo de altura regulable eléctricamente.

A todo ello hay que añadir unos mandos que facilitan enormemente el manejo e incluyen un mini volante de posición regulable. Esto ayuda a reducir al mínimo el riesgo de lesiones por esfuerzos repetidos (RSI) y las consiguientes bajas por enfermedad. Se conecta a un sistema de dirección asistida eléctrica progresiva con ajuste automático de la sensibilidad. Un reposabrazos regulable y de diseño adaptado a la anatomía permite alcanzar con facilidad el resto de los mandos. Bajo la carrocería, los avanzados sistemas de conducción, tracción y control electrónico agilizan y suavizan al máximo cada movimiento de la máquina.

Estas transpaletas ofrecen importantes ventajas frente a la versión con plataforma. En primer lugar, necesitan menos anchura de pasillo (AST), por lo que pueden maniobrar con más rapidez y facilidad en espacios más pequeños. Esto permite estrechar los pasillos y, por tanto, liberar espacio para almacenar más mercancías. Además, las transpaletas eléctricas de conductor sentado no obligan a parar continuamente para plegar o desplegar plataformas o barras laterales.

Otra de sus ventajas es que el habitáculo está contenido en un chasis sólido y resistente que protege al operario. Y es posible añadir un tejadillo protector si existe riesgo de caída de objetos. Este nivel de protección integral proporciona a los trabajadores confianza para moverse con más rapidez por los pasillos. Al efectuar giros y otras maniobras, funciones de estabilización automática como, por ejemplo, el control en las curvas, permiten seguir operando con rapidez y seguridad.

Al igual que el resto de las transpaletas eléctricas de Cat, la versión de conductor sentado está disponible con baterías de iones de litio o de plomo-ácido. La tecnología de iones de litio proporciona alta productividad de forma ininterrumpida y máxima eficiencia.

  • Robust construction and component sealing minimises damage and wear, even in demanding multi-shift operations.
  • Multifunctional display option with onboard diagnostics encourages correct use of truck and speeds up maintenance.
  • PIN code identification prevents unauthorised use, while choice of PRO, ECO and EASY modes matches truck performance to operator experience and application. (Only with multifunctional display option.)
  • Easy, fail-safe battery lock avoids delays and accidents at exchanges.
  • Fast maintenance access features, including a swing-out seat, combine with low servicing requirements and long service intervals to reduce downtime.
  • Availability of fully integrated Li-ion battery increases battery efficiency, runtime and lifespan, while minimising maintenance needs, for even lower total cost of operation (TCO).

  • Advanced AC motor and control technology enables fast, smooth and precise driving and load handling.
  • Progressive electric power steering automatically adjusts sensitivity according to speed, for high precision in tight manoeuvres and high stability when travelling fast and straight.
  • Automatic cornering control reduces maximum travel speed according to steering angle, to ensure quick but safe, stable and confident turns.
  • Angled fork tips permit faster pallet entry with less risk of damage.
  • With Li-ion battery, performance is enhanced and fast opportunity charging is possible, via easily accessible connector, for continuous operation without battery changes.
  • With lead-acid battery, an optional plug on the machine housing allows quick and easy charging without disconnecting the battery.
  • Battery on steel rollers (option on Junior) with bearings enables rapid changes, when necessary, with minimal interruption of productivity.
  • High ground clearance avoids sticking on ramps and uneven floors.
  • 360-degree steering option enables fluid turning without stopping to change direction.
  • Increased drive speed option gives maximum of 10 km/h with load leading and 12 km/h with load trailing.

  • Enclosed operator position ensures all-round protection by heavy-duty chassis, integrated bumper and – optionally – overhead guard pillars and roof.
  • Comfortable operator compartment minimises strain and tiredness with low step-in height, unobstructed floor, comfortable, adjustable suspension seat, minimal vibration and plenty of space for drivers of all sizes.
  • Electrically adjustable floor height (70 mm) option combines with adjustment of armrests and seat to give the perfect fit for each driver.
  • Adjustable mini steering wheel on floating armrest allows a relaxed operator posture, proven to reduce neck/back strain and risk of RSI, and quickly folds up for easy entry/exit.
  • Midi steering wheel option offers adjustable column length and angle, and folds up for easy entry/exit.
  • Height-adjustable armrest comfortably supports wrist while positioning hand ideally to operate fingertip hydraulic levers and other controls simultaneously.
  • Hand-operated direction switch option offers alternative to switching via pedal.
  • Clear all-round and fork-tip view is achieved through careful design of fork carriage, overhead guard, pillars and chassis, and by lowreflection surfaces.
  • Optional overhead guard can be specified with alternative designs such as panoramic, transparent, polycarbonate roof for high upward visibility and additional protection from falling objects.
  • Low-noise specification includes quiet, temperature-controlled fans and speed-regulated lift pump motors, for a pleasant operator environment.
  • Working aids include large tool storage compartment – on engine panel and accessible from outside truck – plus holders for smaller equipment, phone and drinks.
  • Intuitive multifunctional display option keeps drivers fully informed and is optimally positioned and angled for clear viewing.

MODEL CAPACITY (kg) LOAD CENTRE (mm) ENGINE
NPS20N2 2000 600 Battery
NPS30N2 3000 600 Battery
