Quelles que soient les contraintes de votre application, ces modèles thermiques compacts ont hérité à juste titre d’une image synonyme de longévité.

Parfaits pour les applications industrielles, ces chariots offrent une traction exceptionnelle en pente et sur les surfaces glissantes, tout comme les PPS (Pneumatiques Pleins Souples) procurent un excellent confort pour le cariste.

Les modèles DP sont équipés de moteurs Diesel industriels puissants, réputés pour leur fiabilité, leur performance, leurs faibles rejets polluants et leur consommation réduite.

  • Modern design techniques in combination with long component life result in a long service interval which reduces total cost of ownership.
  • Vehicle Control Module manages various truck and operator functions, allowing easy troubleshooting and pinpointing of problems.
  • LCD display provides extensive information on truck operation, maintenance state and soot level (diesel) - with indication of service requirements to prevent unexpected downtime and costs due to unscheduled servicing and repairs.
  • LED front work lights and front/rear combination lights reduce energy consumption and maintenance costs.
  • Robust and durable chassis is fitted with full belly guard to protect engine compartment from dust, water and dirt.

  • Fully floating powertrain layout lowers centre of gravity, increases truck stability and maximises residual lifting capacities.
  • Reliable, high performance, electronically controlled Stage V diesel engine delivers low emission levels with low fuel consumption.
  • Compact design means this range is also suitable for use in aisles with tight spaces.
  • Mast carriage features six bearings, increasing durability and lifting speed, while powerful hydraulic system offers high residual capacities for easy handling of heavier loads.
  • Optional factory-fitted panel cabin keeps the elements out, without compromising visibility, combining form and function in a design which keeps the truck performing in the most extreme of temperatures and in wet environments.

  • Presence Detection System (PDS) prevents truck operation when operator is not seated.
  • Low noise levels combine with the ergonomic and comfortable Grammer seat to help maintain operator concentration and reduce fatigue during long shifts.
  • Fingertip hydraulic controls are mounted on a fully adjustable armrest for optimum load handling and easy manoeuvrability.
  • Automotive-style pedal layout allows easy and comfortable operation.
  • Adjustable steering column with memory position can be set according to operator’s preference for comfortable operation.
  • Low step in chassis enables easy on and off access.
  • Good all-round visibility and ergonomic layout of all controls improves comfort and minimises operator fatigue.
  • Hand grip mounted at the rear of the overhead guard, with a horn button, increases safety and reduces back strain and fatigue in applications involving repetitive reversing.

  • Dust proof kitLine filter for torque converter
  • Tilt cylinder boot kit
  • Lifting eyes mounted on counter weight
  • 3-way control valve FC
  • 4-way control valve MC
  • 4-way control valve FC
  • Loose mast
  • Lifting eye for mast
  • Heavy Load side roller (*Cannot be combined with an integral sideshifter)
  • Side shifter 1000 mm
  • Integral side shifter 1000 mm
  • Fork deletion
  • Indicator kit
  • LED rear work light
  • Rotating beacon (orange)
  • Strobe light (orange)
  • Grammer MSG 65 Cloth seat
  • Rear view mirrors (not available with Deluxe Cabin)
  • Deluxe Cabin
  • Pneumatic tyres
  • Solid pneumatic dual drive tyres
  • Pneumatic dual drive tyres
  • Double element air cleaner
  • Elevated exhaust

MODEL CAPACITY (kg) LOAD CENTRE (mm) ENGINE
DP20N3 2000 500 Diesel
DP25N3 2500 500 Diesel
DP30N3 3000 500 Diesel
DP35N3 3500 500 Diesel
