NSV12-16N3(I)/NSF12-16N3(I)(R)(S) platform stapelaars – ideaal voor intensieve en veelzijdige magazijntaken, zoals in- en uitslag tot 5,4m hoogte, intern transport en orderpicken.
De snelle, verfijnde, stabiele en veiligheidsbevorderende prestaties van deze veelzijdige platform stapelaars geven de bestuurder volop vertrouwen. Voeg daar de opmerkelijk compacte afmetingen, het lage gewicht en de eenvoudige, nauwkeurige bediening aan toe en u heeft alles in huis om de productiviteit te verhogen. Verder zorgen deze trucks voor lagere bedrijfskosten, vooral door de robuuste constructie en het minimale onderhoud.
Cat® stapelaars met platform kunnen verschillende taken uitvoeren in intensieve productie- of logistieke omgevingen. Natuurlijk zijn ze geschikt voor het wegzetten en pakken van lasten in hogere magazijnen, maar ook voor het aanvoeren van producten of orderverzamelen.
Kies uit modellen met een opklapbaar platform (NSV), met de optionele zijsteunen of voor modellen met een vast platform (NSF). Bij de modellen met vast platform en omsluitende steunen kan er gekozen worden tussen een opstap aan de zijkant (S) of aan de achterkant (R). Met een initiële lift heeft u extra bodemvrijheid of kan er gemakkelijk op een helling worden gewerkt. Met deze functie kunnen ook twee modellen tegelijk worden vervoerd en dat verhoogt de productiviteit. Bij al onze platform stapelaars kunt u kiezen uit drie verschillende besturingsmogelijkheden.
Het ontwerp van de platform stapelaars is afgestemd op de bestuurder en dat blijkt ook uit het zeer stabiele en wendbare chassis. De bestuurder voelt zich één met de geavanceerde en ergonomische emPower disselkop. Vanaf het moment dat hij of zij met de truck gaat werken, voelt de stapelaar vertrouwd. De balans tussen een reactieve besturing en hoge prestaties betaalt zich elke werkdag uit.
De disselkop met de eenvoudig bereikbare en gebruikersvriendelijke bedieningselementen zorgt voor een accurate en veilige wendbaarheid. Krachtige motoren met een geavanceerde besturingstechniek bieden meer snelheid en veiligheid bij het rijden en het hanteren van lasten. De output krijgt een boost, terwijl het risico op ongelukken (en de bijbehorende kosten) wordt verlaagd.
Vermoeidheid en stress worden dankzij een soepele en comfortabele gebruikerservaring geminimaliseerd en dat geldt ook voor het ziekteverzuim. De effectieve demping van platform en mast op de platform stapelaars is cruciaal voor het comfort. Op modellen met een vast platform kunt u zelfs kiezen voor een elektrisch verstelbare demping.
De ongekende mogelijkheden dankzij het delen van dezelfde onderdelen tussen alle stapelaars en pallet trucks bieden extra voordeel. Zo kunnen reparaties sneller worden uitgevoerd met minimale stilstand. Ook kan de voorraad reserve onderdelen worden verlaagd. Minder onderhoud en minder ritten van de servicewagens betekenen ook een kleinere CO2 voetafdruk. Win-win voor iedereen!
Net als bij onze andere staplaars, kunt u bij de platform modellen kiezen uit een loodzuur of Li-ion batterij. Li-ion biedt extra voordelen bij het werken in ploegendiensten, waar non-stop moet worden gepresteerd.
- Fully weather-protected and impact-resistant tiller head is sealed to IP65 standard and reinforced for high durability.
- Sealing of connectors, sensors and other key components combines with robust construction, shock and accident resilience, long service intervals and fast access features – including removable motor cover – to reduce maintenance needs and improve uptime.
- Durable design features include heavy-duty chassis, large-diameter drive wheel, protected display location, inductive operator presence sensors, and more, for long life with minimal servicing.
- Li-ion battery (if chosen) gives maximum lifespan, efficiency and runtime.
(Both Li-ion and lead-acid versions are available.) - Advanced motors, regenerative braking and efficient mast designs save on energy (and hydraulic oil consumption).
- Standard display includes BDI (battery discharge indicator) to help prevent damaging deep discharge and support optimal timing of battery changes.
- Multifunctional display option offers clear information on truck and battery condition, faults and actions, and enables setting of operator IDs and PIN code access to avoid unauthorised truck use.
- High levels of component sharing maximise parts availability – and reduce downtime, stock and carbon costs – across the Cat stacker and power pallet ranges.
- Initial lift (I) models allow clearance under load (197 mm from floor to top of load legs; 200 mm to top of forks) for easier working on steep ramps and loading docks.
- Double pallet handling capability halves the number of transport movements required. (Initial lift models.)
- Pallet-stopping heel on load legs helps align loads for much easier, faster and safer double handling. (Initial lift models.)
- Compact and lightweight chassis works with easy, accurate steering to allow rapid manoeuvring and tight turns in narrow aisles.
- Fully integrated Li-ion technology makes continuous operation possible, without battery changes, using fast opportunity charging during short breaks. (Both Li-ion and lead-acid versions are available.)
- Quick battery lock together with bearing-mounted steel roller option speeds up changes. (For lead-acid batteries.)
- Exceptional levels of comfort, control, traction and stability keep operators alert, motivated and productive, however intense their workload.
- Three performance modes are selectable to suit individual users and applications: Power for advanced operators and intensive operations; Eco to blend low energy consumption with high productivity; Easy for learners and for handling sensitive goods. (Available only with multifunctional display option.)
- Latest AC drive motor technology combines high power with advanced electronic control, a large-diameter drive wheel and strong regenerative braking for a confident, fast, smooth and precisely controlled ride.
- Powerful and quiet hydraulic motor is smoothly governed by stepless, speedregulated lifting and lowering control, for quick but safe and accurate load positioning and movement.
- Fork shape is tapered on the underside as well as pointed at the tip, to avoid sticking, for easier and faster pallet entry and exit even while turning at the same time.
- Operator-centric chassis design optimises traction according to load weight and maintains safe stability, while providing excellent manoeuvrability, for instant user confidence and continuous top-class performance in fast-paced, high-level stacking operations.
- Active Spin Reduction (ASR) option aids traction on slippery surfaces.
- Best-in-class emPower ergonomic tiller head gives easier access to controls with a unique patented design that achieves the optimum distance between hand and lift/lower buttons.
- Ergonomically designed tiller head operating features include optimised handle shape and cross-section, large hand space, and enlarged horn and lift/lower buttons, as well as user-friendly speed and brake controls.
- Butterfly-type, dual-direction speed and brake control design provides seven convenient finger positions for comfortable, low-effort, precise operation.
- Dual controls allow easy reach with either hand and can be used accurately even when wearing gloves.
- Tiller-type power steering via a short tiller arm features a hydraulic damper and works without physical connection to the drive wheel – avoiding transmission of bumps, twists and turns, while enabling comfortable, controlled, precise manoeuvring. (Available on folding platform and rearentry fixed platform models.)
- Comfort Steering via a tiller head without an arm – as on an electric scooter – maximises power-steered control and precision, with the aid of a damper, while avoiding shock, vibration, strain and fatigue in the operator’s hands, wrists and arms. (Available on fixed platform models.)
- Mechanical (non-powered) steering option uses a compact tiller arm to provide a simple, economical, durable, low-effort manoeuvring solution for less intense work environments. (Only available on folding platform models.)
- Tiller up drive option allows manoeuvring with tiller arm vertical, to move through the tightest spaces. (Available on folding platform models with mechanical or power steering.)
- Electronic steering technology automatically adjusts sensitivity according to steered angle and truck speed, and gives resistance and feedback, for controlled travel and full confidence. (On all power-steered trucks.)
- Cornering control constantly monitors steering angle, travel rate and quickness of tiller head movement – automatically adjusting the turning speed to maintain safe motion. (On all power-steered trucks.)
- Mast and fork carriage design and engineering advances improve forward and fork-tip views, while enhancing the user experience with smoother, quieter lifting and lowering.
- Extensive mast choice includes duplex and triplex versions with a range of standard and custom lift heights.
- High-comfort damping on both folding and fixed platforms minimises impacts on the knees, especially, and acts progressively with increasing operator weight, while ergonomic controls and steering further reduce effort and fatigue.
- Unique electrically adjustable damping option on fixed platform models is optimised for each operator’s weight and preference at the touch of a button, providing a cost-effective increase in comfort.
- Overhead guard protects operator from falling goods. (Standard on fixed platform models. Optional on folding platform models, but only with power steering.)
- Optional protective side bars on folding platform models are deployed quickly and simply – with one hand – to help avoid falls and defend against impacts. (Top speed is increased when side bars are used.)
- Fixed platform models give extra protection and comfort, with low step height – for easy entry/exit – and a choice of rear and side entry barrier designs.
- Optional foot protection system automatically slows/stops the truck if foot is outside platform. (Rear entry fixed platform models.)
- Rugged build includes compact but heavy-duty chassis, cast-iron platform and integrated low-profile bumper to resist deformation, protect the operator and reduce foot-trapping risk.
MODEL | CAPACITY (kg) | LOAD CENTRE (mm) | ENGINE |
---|---|---|---|
NSV12N3 | 1250 | 600 | Elektrisch |
NSV12N3I | 1250 | 600 | Elektrisch |
NSV16N3 | 1600 | 600 | Elektrisch |
NSV16N3I | 1600 | 600 | Elektrisch |
NSF12N3R | 1250 | 600 | Elektrisch |
NSF12N3IR | 1250 | 600 | Elektrisch |
NSF16N3R | 1600 | 600 | Elektrisch |
NSF16N3IR | 1600 | 600 | Elektrisch |
NSF12N3S | 1250 | 600 | Elektrisch |
NSF12N3IS | 1250 | 600 | Elektrisch |
NSF16N3S | 1600 | 600 | Elektrisch |
NSF16N3IS | 1600 | 600 | Elektrisch |
